Image Sensor:  3K CMOS

Max. Resolution:  2960 (H) × 1665 (V)

Min. Illumination:  0.01 Lux @ (F2.0, AGC ON), 0 Lux with IR

Shutter Time:  PAL: 1/25 s to 1/50, 000 s; NTSC: 1/30 s to 1/50, 000 s

Day & Night:  ICR

Angle Adjustment:  Pan: 0 to 360°, Tilt: 0 to 75°, Rotation: 0 to 360°

Signal System:  PAL/NTSC

Lens

Lens Type:  2.8 mm and 3.6 mm fixed focal lens

Focal Length & FOV

2.8 mm, horizontal FOV: 105°, vertical FOV: 62°, diagonal FOV: 132°

3.6 mm, horizontal FOV: 92°, vertical FOV: 48°, diagonal FOV: 112°

Lens Mount:  M12

Microphone

Pickup DistanceIn a radius of up to 5 m

Amount:  1

Illuminator

Supplement Light Type:  Smart, IR, White Light

Supplement Light Range

IR : Up to 20 m

White Light : Up to 20 m


Image Settings:  Brightness, Sharpness, Smart IR

Frame Rate

TVI: 3K@20 fps, 4 MP@25 fps/30 fps, 1080p@25 fps/30 fps

AHD: 4 MP@25 fps/30 fps

CVI: 4 MP@25 fps/30 fps

CVBS: PAL/NTSC

Day/Night Mode:  Auto/Color

Wide Dynamic Range (WDR):  Digital WDR

Image Enhancement:  DWDR/BLC/HLC/Global

White Balance:  Auto/Manual

AGCYes

Interface

Video Output:  Switchable TVI/AHD/CVI/CVBS

General

Material:  Plastic

Dimension:  84.6 mm × Ø85.02 mm (3.33" × Ø3.35")

Approx. 160 g (0.35 lb.)

Operating Condition-40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation)

Communication:  HIKVISION-C

Language:  English

Power Supply

12 VDC ± 25%

*You are recommended to use one power adapter to supply the power for one camera.

Consumption:  Max. 2.9 W
