About
Learn what makes this product unique and why it’s right for you.
Installation Type:
Wall,Pole
Dimensions without packaging (H x W x D) [mm(in.)]:
270 mm x 196 mm x 51 mm (10.63 in. x 7.72 in. x 2.01 in.)
Dimensions with packaging (H x W x D) [mm(in.)]:
110 mm x 356 mm x 250 mm (4.33 in. x 14.02 in. x 9.84 in.)
Weight without packaging [kg(lb)]:
1.14 kg (2.51 lb)
Weight with packaging [kg(lb)]:
1.78 kg (3.92 lb)
Power supply mode:
PoE
Rated input voltage [V]:
PoE: 802.3at/af
Input voltage range [V]:
PoE: 802.3at/af
Maximum number of physical ports on the entire device
2.5GE (RJ45) x 1, 100M/1000M/2.5G auto-sensing
Long-term operating temperature [°C(°F)]
–30°C to +60°C (–22°F to +140°F) (From 1800 m to 5000 m [5905.51 ft. to 16404.20 ft.], the maximum ambient temperature decreases by 1°C [1.8°F] for every 300 m [984.25 ft.] increase in altitude.)
Long-term operating relative humidity [RH]
Operating humidity: 5% RH to 95% RH Storage humidity: 5% RH to 95% RH (non-condensing)
Ingress protection level (dustproof/waterproof):
IP65
Radio number:
2
MIMO spatial streams:
Radio 0 (2.4 GHz): 2x2 Radio 1 (5 GHz): 2x2
Wi-Fi standard:
2.4 GHz: 802.11b/g/n/ax/be 5 GHz: 802.11a/n/ac/ac Wave 2/ax/be
Radio interface:
Built-in omnidirectional antennas
Antenna gain:
2.4 GHz: 4 dBi/chain (peak value) 2 dBi (combined gain) 5 GHz: 7 dBi/chain (peak value) 4 dBi (combined gain)
Maximum transmit power:
2.4 GHz: 25 dBm/chain 28 dBm (combined power) 5 GHz: 24 dBm/chain 27 dBm (combined power)
Maximum power consumption [W]:
18.8
Operating frequency band:
2.4GHz,5GHz
Maximum channel bandwidth [MHz]:
Radio 0 (2.4 GHz): 40 MHz Radio 1 (5 GHz): 160 MHz
Optimal Signal Distance (m):
130
Max Number of Access Users:
256
Recommended Number of Access Users:
130
Device Rate:
3.57 Gbps
Learn what makes this product unique and why it’s right for you.
Installation Type:
Wall,Pole
Dimensions without packaging (H x W x D) [mm(in.)]:
270 mm x 196 mm x 51 mm (10.63 in. x 7.72 in. x 2.01 in.)
Dimensions with packaging (H x W x D) [mm(in.)]:
110 mm x 356 mm x 250 mm (4.33 in. x 14.02 in. x 9.84 in.)
Weight without packaging [kg(lb)]:
1.14 kg (2.51 lb)
Weight with packaging [kg(lb)]:
1.78 kg (3.92 lb)
Power supply mode:
PoE
Rated input voltage [V]:
PoE: 802.3at/af
Input voltage range [V]:
PoE: 802.3at/af
Maximum number of physical ports on the entire device
2.5GE (RJ45) x 1, 100M/1000M/2.5G auto-sensing
Long-term operating temperature [°C(°F)]
–30°C to +60°C (–22°F to +140°F) (From 1800 m to 5000 m [5905.51 ft. to 16404.20 ft.], the maximum ambient temperature decreases by 1°C [1.8°F] for every 300 m [984.25 ft.] increase in altitude.)
Long-term operating relative humidity [RH]
Operating humidity: 5% RH to 95% RH Storage humidity: 5% RH to 95% RH (non-condensing)
Ingress protection level (dustproof/waterproof):
IP65
Radio number:
2
MIMO spatial streams:
Radio 0 (2.4 GHz): 2x2 Radio 1 (5 GHz): 2x2
Wi-Fi standard:
2.4 GHz: 802.11b/g/n/ax/be 5 GHz: 802.11a/n/ac/ac Wave 2/ax/be
Radio interface:
Built-in omnidirectional antennas
Antenna gain:
2.4 GHz: 4 dBi/chain (peak value) 2 dBi (combined gain) 5 GHz: 7 dBi/chain (peak value) 4 dBi (combined gain)
Maximum transmit power:
2.4 GHz: 25 dBm/chain 28 dBm (combined power) 5 GHz: 24 dBm/chain 27 dBm (combined power)
Maximum power consumption [W]:
18.8
Operating frequency band:
2.4GHz,5GHz
Maximum channel bandwidth [MHz]:
Radio 0 (2.4 GHz): 40 MHz Radio 1 (5 GHz): 160 MHz
Optimal Signal Distance (m):
130
Max Number of Access Users:
256
Recommended Number of Access Users:
130
Device Rate:
3.57 Gbps
Huawei
by
Huawei
AP771
- Regular price
- $250.00
- Sale price
- $250.00
- Regular price
-
Shipping calculated at checkout.
Out of stock
Essential details about the product's features and use.
Essential details about the product's features and use.
Couldn't load pickup availability
Product Note
Please check product specifications (size, compatibility, and model) carefully before purchasing.
